> ADM3202ARNZ-REEL7
ADM3202ARNZ-REEL7 ADI Drivers, Receivers, Transceivers
The ADM3202ARNZ-REEL7 is a high-speed, 2-channel RS-232 line driver/receiver from Analog Devices, specified for a single 3V to 5.5V supply using 0.1µF charge pump capacitors. For selection, verify the wide 3V to 5.5V supply range matches your system, confirm the 460kbps max data rate meets communication needs, and ensure the -40°C to +85°C industrial temperature range covers your environment. This transceiver features ±15kV HBM ESD protection, a 400mV receiver hysteresis for noise immunity, and low power consumption, making it ideal for battery-powered portable instruments. Common applications include general-purpose RS-232 data links, industrial automation, process control systems, printers, PDAs, palmtop computers, mobile gadgets, and data acquisition interfaces. Available in a 16-pin SOIC package. In stock at HL Electronics – request a quote for fast delivery.
Pricing (USD)
| Quantity | Unit Price |
|---|---|
| 1+ | $ 0.57 |
| 100+ | $ 0.45 |
| 1000+ | $ 0.43 |
| 15000+ | $ 0.43 |
| 30000+ | $ 0.43 |
Technical Specifications
- Part No.ADM3202ARNZ-REEL7
- ECCN EAR99
- Type Transceiver
- HTSUS 8542.39.0070
- Duplex Full
- Category Integrated Circuits (ICs) > Interface > Drivers, Receivers, Transceivers
- Features RS-232 line driver/receiver, operates with 0.1µF charge pump capacitors, ±15kV ESD protection on I/O lines, 400mV receiver hysteresis, low power, industrial temperature range
- Protocol RS232
- Data Rate 460kbps
- Packaging Tape & Reel (TR)
- Part Status Active
- RoHS Status ROHS3 Compliant
- Manufacturer Analog Devices Inc.
- REACH Status REACH Unaffected
- Mounting Type Surface Mount
- Standard Package 1000
- Voltage - Supply 3V ~ 5.5V
- Base Product Number ADM3202
- Operating Temperature -40°C ~ 85°C (TA)
- Supplier Device Package 16-SOIC
- Lead Finish / Ball Material Matte Tin (Sn) - annealed
- Number of Drivers/Receivers 2/2
- Moisture Sensitivity Level (MSL) 1 (Unlimited)
