> ADS1110A0IDBVR
ADS1110A0IDBVR TI Analog to Digital Converters (ADC)
The ADS1110A0IDBVR is a precision 16‑bit delta‑sigma ADC from Texas Instruments, featuring a differential input with an onboard 2.048V reference (5ppm/°C drift) and programmable PGA up to 8× in a tiny SOT‑23‑6 package. For selection, verify the I²C interface and address, supply voltage range of 2.7V to 5.5V, flexible data rates of 15SPS to 240SPS, and low power consumption (240µA active, 50nA standby). The device operates from -40°C to +85°C and is well suited for industrial process control, portable instrumentation, smart sensors, factory automation, and temperature measurement. In stock at HL Electronics – request a quote for fast delivery.
Part No.:ADS1110A0IDBVR
Brand:TI
Date Code:26+
Stock:49,183
SPQ:0
MOQ:1+
Delivery Time:In Stock
Pricing (USD)
| Quantity | Unit Price |
|---|---|
| 1+ | $ 0.78 |
| 100+ | $ 0.65 |
| 750+ | $ 0.60 |
| 1500+ | $ 0.57 |
| 3000+ | $ 0.55 |
Technical Specifications
- Part No.ADS1110A0IDBVR
- Category Integrated Circuits (ICs) > Data Acquisition > Analog to Digital Converters (ADC)
- Manufacturer Texas Instruments
- Packaging Tape & Reel (TR)
- Part Status Active
- Number of Bits 16
- Sampling Rate (Per Second) 240
- Number of Inputs 1
- Input Type Differential, Single Ended
- Data Interface I2C
- Configuration PGA-ADC
- Ratio - S/H:ADC -
- Number of A/D Converters 1
- Architecture Sigma-Delta
- Reference Type Internal
- Voltage - Supply, Analog 2.7V ~ 5.5V
- Voltage - Supply, Digital 2.7V ~ 5.5V
- Features PGA, Oscillator, Small Size, Selectable Address
- Operating Temperature -40°C ~ 125°C
- Mounting Type Surface Mount
- Supplier Device Package SOT-23-6
- Base Product Number ADS1110
- Moisture Sensitivity Level (MSL) 1 (Unlimited)
- RoHS Status ROHS3 Compliant
- REACH Status REACH Unaffected
- ECCN EAR99
- HTSUS 8542.39.0030
- Standard Package 3000
