DRV8251ADDAR TI Motor Drivers, Controllers

The DRV8251ADDAR is a highly integrated 50‑V, 4.1‑A peak H‑bridge brushed DC motor driver from Texas Instruments, featuring integrated current‑sense feedback (IPROPI) and current regulation via a current mirror, eliminating the need for external power shunt resistors. For selection, verify motor supply voltage (VM) from 4.5 V to 48 V; confirm peak output current up to 4.1 A; note PWM control interface compatible with 1.8 V, 3.3 V, and 5 V logic inputs; ensure 8‑pin HSOP with PowerPAD package fits your layout; and check integrated protections including undervoltage lockout (UVLO), auto‑retry overcurrent protection (OCP), and thermal shutdown (TSD). Operating junction temperature ranges from –40 °C to +150 °C. Housed in a small 4.9 mm × 6.0 mm HSOP package, the device also features a low‑power sleep mode with <1 µA quiescent current. Ideal for printers and scanners, office automation machines, robotics and automated guided vehicles (AGVs), small pumps and fans, conveyor belt drives, medical equipment (breathing machines, infusion pumps, adjustable beds), solenoid and valve control, consumer electronics (coffee machines, electric curtains, smart locks), and industrial automation systems requiring precise brushed DC motor control. In stock at HL Electronics – request a quote for fast delivery.
