> DS90UB948TNKDRQ1
DS90UB948TNKDRQ1 TI Serializers, Deserializers
The DS90UB948TNKDRQ1 is an automotive AEC-Q100 qualified dual FPD-Link III deserializer from Texas Instruments that converts FPD-Link III streams (from DS90UB949/947-Q1 serializers) into an OpenLDI (LVDS) display interface supporting resolutions up to 2K (2048x1080) with 24‑bit color depth (192 MHz pixel clock). For selection, verify supply voltages (VDDIO: 1.71–1.89V; VDD33: 3–3.6V), confirm the data rate capability of 3.36 Gbps, ensure the operating temperature range of -40°C to +105°C meets your environment, and validate the required pixel clock and resolution. Applications include automotive infotainment and cluster displays, rear‑seat entertainment, industrial high‑resolution monitors, and any system requiring long‑distance (up to 15m) video and control data (I2C, SPI, GPIO, I2S audio) over shielded twisted‑pair or coaxial cables. In stock at HL Electronics – request a quote for fast delivery.
Pricing (USD)
| Quantity | Unit Price |
|---|---|
| 1+ | $ 5.62 |
| 100+ | $ 5.11 |
| 1000+ | $ 4.96 |
| 2000+ | $ 4.84 |
Technical Specifications
- Part No.DS90UB948TNKDRQ1
- Category Integrated Circuits (ICs) > Interface > Serializers, Deserializers
- Manufacturer Texas Instruments
- Packaging Tape & Reel (TR)
- Part Status Active
- Function Deserializer
- Data Rate 3.36Gbps
- Input Type FPD-Link III, LVDS
- Output Type LVDS
- Number of Inputs 2
- Number of Outputs 8
- Voltage - Supply 1.71V ~ 1.89V, 3V ~ 3.6V
- Operating Temperature -40°C ~ 105°C (TA)
- Grade Automotive
- Qualification AEC-Q100
- Mounting Type Surface Mount
- Supplier Device Package 64-WQFN (9x9)
- Base Product Number DS90UB948
- Features 3.36Gbps, 2K Resolution, AEC-Q100 Level 2, Adaptive Equalizer, SPI/I2C Controls, 8 LVDS Outputs, ISO 26262 Functional Safety
- Moisture Sensitivity Level (MSL) 3 (168 Hours)
- RoHS Status ROHS3 Compliant
- REACH Status REACH Unaffected
- Lead Finish / Ball Material Sn
- ECCN EAR99
- HTSUS 8542.39.0070
- Standard Package 2000
