> LMR62421XMFX/NOPB
LMR62421XMFX/NOPB TI DC DC Switching Regulators
The LMR62421XMFX/NOPB is a SIMPLE SWITCHER® 2.1A low‑side switch regulator from Texas Instruments ideal for Boost and SEPIC DC-DC regulation. For selection, verify input voltage from 2.7V to 5.5V, ensure adjustable output up to 24V, confirm switch current ≤2.1A, check fixed 1.6MHz switching frequency, and note the -40°C to 125°C junction temperature range. Typical applications include battery-powered equipment, LCD bias supplies, portable instruments, USB power adapters, white LEDs, DSL/cable modems, and local boost converters in industrial control and automotive systems. In stock at HL Electronics – request a quote for fast delivery.
Part No.:LMR62421XMFX/NOPB
Brand:TI
Date Code:25+
Stock:58,160
SPQ:0
MOQ:1+
Delivery Time:In Stock
Pricing (USD)
| Quantity | Unit Price |
|---|---|
| 1+ | $ 0.54 |
| 100+ | $ 0.45 |
| 750+ | $ 0.41 |
| 1500+ | $ 0.39 |
| 3000+ | $ 0.38 |
Technical Specifications
- Part No.LMR62421XMFX/NOPB
- Category Integrated Circuits (ICs) > Power Management (PMIC) > Voltage Regulators > DC DC Switching Regulators
- Manufacturer Texas Instruments
- Packaging Tape & Reel (TR)
- Part Status Active
- Function Step-Up
- Output Configuration Positive
- Topology Boost
- Output Type Adjustable
- Number of Outputs 1
- Voltage - Input (Min) 2.7V
- Voltage - Input (Max) 5.5V
- Voltage - Output (Min/Fixed) 2.7V
- Voltage - Output (Max) 24V
- Current - Output 2.1A (Switch)
- Frequency - Switching 1.6MHz
- Synchronous Rectifier No
- Operating Temperature -40°C ~ 125°C (TJ)
- Mounting Type Surface Mount
- Supplier Device Package SOT-23-5
- Base Product Number LMR62421
- Features 1.6MHz, 2.1A Switch, Low Shutdown Iq (80nA), Up to 24V Vout, Cycle-by-Cycle Current Limiting, Internal Soft-Start, Thermal Shutdown
- Moisture Sensitivity Level (MSL) 1 (Unlimited)
- RoHS Status ROHS3 Compliant
- REACH Status REACH Unaffected
- Lead Finish / Ball Material Sn
- ECCN EAR99
- HTSUS 8542.39.0070
- Standard Package 3000
