> PCA9306DCTR
PCA9306DCTR TI Translators, Level Shifters
The PCA9306DCTR is a 2-bit bidirectional voltage-level translator from Texas Instruments in 8-pin SSOP (DCT) package, designed for I2C and SMBus applications. For selection, verify A-port supply (VREF1) from 1.2V to 3.3V and B-port supply (VREF2) from 1.8V to 5.5V, I2C clock up to 400kHz, EN pin for bus isolation, low on-resistance of 15Ω typical, propagation delay of 900ps, output current of 64mA, and operating temperature from -40°C to +85°C. Features include no direction pin required, ultra-low propagation delay, and bidirectional translation between 1.2V, 1.8V, 2.5V, 3.3V and 5V nodes. Ideal for I2C, SMBus, PMBus, and GPIO interfaces in servers, routers, PCs, telecom equipment, industrial automation, and mixed-voltage systems. In stock at HL Electronics – request a quote for fast delivery.
Pricing (USD)
| Quantity | Unit Price |
|---|---|
| 1+ | $ 0.20 |
| 100+ | $ 0.15 |
| 750+ | $ 0.13 |
| 1500+ | $ 0.12 |
| 3000+ | $ 0.11 |
Technical Specifications
- Part No.PCA9306DCTR
- Model PCA9306DCTR
- Category Integrated Circuits (ICs) > Logic > Translators, Level Shifters
- Manufacturer Texas Instruments
- Packaging Tape & Reel (TR)
- Part Status Active
- Type Voltage Level Translator
- Number of Circuits 1
- Channels per Circuit 2
- Voltage - VCCA 1.2 V ~ 3.3 V
- Voltage - VCCB 1.8 V ~ 5.5 V
- Output Type Open Drain
- Features Auto Direction Sensing
- Operating Temperature -40°C ~ 85°C (TA)
- Mounting Type Surface Mount
- Supplier Device Package 8-SSOP
- Base Product Number PCA9306
- RoHS ROHS3 Compliant
- Standard Package 3000
