> TMS320F28377DPTPT
TMS320F28377DPTPT TI Microcontroller
TMS320F28377DPTPT is a dual‑core C2000™ Delfino™ 32‑bit MCU from Texas Instruments featuring two 200MHz C28x CPUs and two Control Law Accelerators (CLA) delivering 800 MIPS of floating‑point performance. Select based on core voltage (1.14V–3.47V), 1MB flash, 204KB RAM, 176‑pin HLQFP package, and –40°C to 105°C junction temperature. It integrates a Trigonometric Math Unit (TMU), up to four 16‑bit ADCs, multiple high‑resolution PWMs, CAN, SPI, I2C, UART, USB 2.0, and EMIF for external memory expansion. Ideal for advanced closed‑loop control applications such as industrial motor drives, servo control, solar inverters, digital power supplies, electric vehicle powertrains, renewable energy systems, and real‑time signal processing. In stock at HL Electronics – request a quote for fast delivery.
Pricing (USD)
| Quantity | Unit Price |
|---|---|
| 1+ | $ 10.56 |
| 10+ | $ 9.60 |
| 40+ | $ 9.37 |
Technical Specifications
- Part No.TMS320F28377DPTPT
- Category Integrated Circuits (ICs) > Embedded > Microcontrollers
- Manufacturer Texas Instruments
- Packaging Tray
- Part Status Active
- Core Processor C28x
- Core Size 32-Bit Dual-Core
- Speed 200MHz
- Connectivity CANbus, EBI/EMI, I2C, McBSP, SCI, SPI, uPP, UART/USART, USB
- Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
- Number of I/O 97
- Program Memory Size 1MB (512K x 16)
- Program Memory Type FLASH
- RAM Size 102K x 16
- Voltage - Supply (Vcc/Vdd) 1.14V ~ 3.47V
- Data Converters A/D 20x12b, 9x16b; D/A 3x12b
- Oscillator Type Internal
- Operating Temperature -40°C ~ 105°C (TJ)
- Grade Catalog
- Mounting Type Surface Mount
- Supplier Device Package 176-HLQFP (24x24)
- Base Product Number TMS320
- Features 800 MIPS, Dual-Core, FPU, TMU, VCU-II, 2x CLA, 2x EMIF, 2x 6ch DMA, 169 GPIO, USB 2.0, 4x ADC (16b/12b), 24x PWM, 16x HRPWM, 8x SDFM, Functional Safety, Dual-zone Security
- Moisture Sensitivity Level (MSL) 3 (168 Hours)
- RoHS Status ROHS3 Compliant
- REACH Status REACH Unaffected
- Lead Finish / Ball Material NiPdAu
- ECCN 3A991A2
- HTSUS 8542.31.0025
- Standard Package 40
