> TPS54160DGQR
TPS54160DGQR TI DC DC Switching Regulators
The TPS54160DGQR is a 60‑V, 1.5‑A step‑down converter from Texas Instruments with an integrated high‑side MOSFET and Eco‑mode for light‑load efficiency. For selection, verify an input range of 3.5 V to 60 V, confirm adjustable output from 0.8 V to 58 V, and check the 1.5‑A maximum output current; the switching frequency is programmable from 100 kHz to 2.5 MHz, quiescent current is 116 µA (1.3‑µA shutdown), and the junction temperature range is –40 °C to 150 °C. It includes a power‑good flag, adjustable soft‑start, overcurrent and thermal protection. Typical applications include 12‑V, 24‑V and 48‑V industrial systems, automotive aftermarket power supplies, control boards, instrumentation, battery‑powered equipment, PoE, and telecom distribution buses. In stock at HL Electronics – request a quote for fast delivery.
Pricing (USD)
| Quantity | Unit Price |
|---|---|
| 1+ | $ 0.30 |
| 100+ | $ 0.23 |
| 1250+ | $ 0.20 |
| 2500+ | $ 0.19 |
Technical Specifications
- Part No.TPS54160DGQR
- ECCN EAR99
- Grade Catalog
- Category Integrated Circuits (ICs) > Power Management (PMIC) > Voltage Regulators > DC DC Switching Regulators
- Function Step-Down
- Topology Buck
- Packaging Tape & Reel (TR)
- Output Type Adjustable
- Part Status Active
- RoHS Status ROHS3 Compliant
- Manufacturer Texas Instruments
- REACH Status REACH Unaffected
- Mounting Type Surface Mount
- Current - Output 1.5 A
- Standard Package 2500
- Number of Outputs 1
- Base Product Number TPS54160
- Output Configuration Positive
- Frequency - Switching 100 kHz ~ 2.5 MHz
- Operating Temperature -40°C ~ 150°C (TJ)
- Synchronous Rectifier No
- Voltage - Input (Max) 60 V
- Voltage - Input (Min) 3.5 V
- Voltage - Output (Max) 58 V
- Supplier Device Package 10-HVSSOP
- Lead Finish / Ball Material NiPdAu
- Voltage - Output (Min/Fixed) 0.8 V
- Moisture Sensitivity Level (MSL) 1 (Unlimited)
