IRLMS2002TRPBF Infineon Power MOSFET

IRLMS2002TRPBF - Infineon - main product image
Part No.:IRLMS2002TRPBF
Brand:Infineon
Date Code:
Stock:3,000
SPQ:0
MOQ:1+
Delivery Time:In Stock

Pricing (USD)

QuantityUnit Price
1+ $ 0.25
100+ $ 0.20
750+ $ 0.18
1500+ $ 0.17
3000+ $ 0.16
18000+ $ 0.16
39000+ $ 0.16

Technical Specifications

  • Part No.IRLMS2002TRPBF
  • Series HEXFET®
  • Category Discrete Semiconductor Products > Transistors > FETs, MOSFETs > Single
  • FET Type N-Channel
  • Packaging Tape & Reel (TR)
  • Vgs (Max) ±12V
  • Technology MOSFET (Metal Oxide)
  • FET Feature -
  • Part Status Active
  • Mounting Type Surface Mount
  • Vgs(th) (Max) @ Id 1.2V @ 250µA
  • Operating Temperature -55°C ~ 150°C (TJ)
  • Rds On (Max) @ Id, Vgs 30 mOhm @ 6.5A, 4.5V
  • Power Dissipation (Max) 2W (Ta)
  • Supplier Device Package Micro6™(SOT23-6)
  • Gate Charge (Qg) (Max) @ Vgs 22nC @ 5V
  • Drain to Source Voltage (Vdss) 20V
  • Input Capacitance (Ciss) (Max) @ Vds 1310pF @ 15V
  • Current - Continuous Drain (Id) @ 25°C 6.5A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
📧 📋 💬
