STD35NF06T4 ST Power MOSFET

STD35NF06T4 - ST - main product image
Part No.:STD35NF06T4
Brand:ST
Date Code:
Stock:3,000
SPQ:0
MOQ:1+
Delivery Time:In Stock

Pricing (USD)

QuantityUnit Price
1+ $ 0.45
100+ $ 0.37
1250+ $ 0.34
2500+ $ 0.33
37500+ $ 0.32
50000+ $ 0.32

Technical Specifications

  • Part No.STD35NF06T4
  • Series STripFET™ II
  • Category Discrete Semiconductor Products > Transistors > FETs, MOSFETs > Single
  • FET Type N-Channel
  • Packaging Tape & Reel (TR)
  • Vgs (Max) ±20V
  • Technology MOSFET (Metal Oxide)
  • FET Feature -
  • Part Status Active
  • Mounting Type Surface Mount
  • Vgs(th) (Max) @ Id 4V @ 250µA
  • Operating Temperature -55°C ~ 175°C (TJ)
  • Rds On (Max) @ Id, Vgs 20 mOhm @ 17.5A, 10V
  • Power Dissipation (Max) 80W (Tc)
  • Supplier Device Package D-Pak
  • Gate Charge (Qg) (Max) @ Vgs 60nC @ 10V
  • Drain to Source Voltage (Vdss) 60V
  • Input Capacitance (Ciss) (Max) @ Vds 1300pF @ 25V
  • Current - Continuous Drain (Id) @ 25°C 35A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On) 10V
📧 📋 💬
